MZ10 Plus Iron Removal

100 Onwards INR/Kilograms

Request To Call Back Send Inquiry

Price And Quantity

MZ10 Plus Iron Removal

USP:-

Can take max iron concentrations up to 20 ppm
Can reduce iron, Mn and H2 S up to < 0.1 ppm
No limitation of dissolved oxygen
No limitation of alkalinity and TDS in water
Needs only periodic backwash with treated water
Can be operated at high temperatures and high differential pressures without breakdown of media No pre-treatment required to remove chlorine in feed water
Used with chlorine, the media offers excellent resistance to biological contamination
NSF approved

Appearance	Black granules shipped in a dry form
Specific Gravity	Approximately 2.4
Capacity	490 to 840 gm/m2 of bed area
Screen Size Range (dry)	-16 + 60 B.S.S. Std. Mesh
Particle Size Range (dry)	0.25 mm to 1.2 mm
Effective Size	0.30 0.35 mm
Uniformity Coefficient	Less than 1.6
Shipping Weight	Approx. 1450 g/l
Porosity	Approx. 0.45

RECOMMENDED OPERATING CONDITIONS

pH Range	6.2 8.5
Max Operating Temperature	No Specific limit
Max Differential Pressure across the Bed	0.85 kg/cm2
Backwash Characteristics	30 m3/hr/m2 minimum
Service Flowrate	5 30 m3/hr/m2
Minimum Bed Depth	700 mm (400 mm min each if dual media is used)
